GS-1890

Light Source

Visible Laser Diode 650nm

Scan Pattern

Single Scan

Scan Rate

200 times/second

Scan Precision

4mil

Scan Width

30mm@scan window, 220mm@200mm

Scan Depth of field

0-350mm (0.33mm pcs0.9)

Decode Capability

EAN-8, EAN-13, UPC-A,UPC-E,Code 39, Code 128, EAN128, Codabar, Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, MSI, etc.

Tilt

30

Elevation Angle

65

Deflection Angle

55

Support Inferface

RS232, PS2 and USB

Print Contrast

30% UPC/EAN 100%

Mention Pattern

Buzzer, Indicator

Scan Mode

Manual & continue scanning

MECHANICAL PARAMETER

Size

L x W x H: 180mm x69mm x 92mm

Weight

150g

Material

ABS + PC

Cable

Standard 1.8M straight

ELECTRICAL PARAMETER

Voltage

5VDC

Operating Current

85mA peak current (120 mA )

Static Current

36mA

Laser Class

Meet the Grade I National Criteria for Laser Safety

EMC

CE & FCC DOC compliance

ENVIRONMENTAL PARAMETER

Operating Temperature

0°C to 45°C

Storage Temperature

-20°C to 60°C

Humidity

5% to 85% relative humidity, non-condensing

Light Levels

Daylight, 5000Lux

Shock

Designed to withstand 1.5M drops
